XS Line Auto Dry Cabinets offer between 300-900 liter volume within three different drying technologies
XS LINE DESICCANT DRY CABINETS
X-Treme Series XS Line Desiccant Dry Cabinets have been specifically designed for drying and storing moisture sensitive devices (MSDs). According to IPC/JEDEC J-STD 033C ve IPC-1601 standards, moisture-sensitive materials and PCB’s can be stored in these cabinets for an unlimited period of time. XS Line Desiccant Dry Cabinets are suitable for low and medium volume production due to cabinet dimensions also it can be used for baking (floor life resetting) purposes with optional heater units up to 100ᵒC degree. Due to the long depth of the cabinet, feeder storage solutions can be added or used for the storage of large-scale products. XS Line Desiccant Dry Cabinets are equipped with a patented drying unit DHM-01. The patented DHM-01 desiccant drying unit guarantees constant low relative humidity ≤0.5%RH for short to long-term storage thus oxidation risks associated with long term storage can be avoided. Ideal for the moisture-proof and anti-oxidation storage of wide-ranging technologies.
The drying unit of X-Treme Series Auto Dry Cabinets operating at very low humidity levels and optional heating units works together to provide a fast and healthy baking process at low temperatures for floor life resetting process. It provides a larger area and a more controlled drying environment compared to traditional ovens. Low-temperature baking prevents problems such as delamination, micro-cracks, popcorn affects, and solderability in MSDs (Moisture Sensitive Devices) arising due to high-temperature stress on the materials after baking in traditional ovens.
The touch screen control panel provides 800x480px resolution in 7″ touch-capable area. The user can reach all important data in the cabinets with simple clicks. X-Treme Series Auto Dry Cabinets fully network compatible, it can be reached remotely via computers, phones, and tablets which are using Wi-Fi and ethernet connections. The cabinets are equipped with high-precision sensors and integrated data logger for performance traceability.
X-Treme Series Auto Dry Cabinets are ESD Safe and conforms to the current ESD 61340-5-1 standards with optional ESD-safe coating
External Dimensions (WxHxD):
606 x 1128 x 750 mm
Internal Dimensions (WxHxD):
Non Insulated: 603 x 792 x 630 mm
Insulated: 584 x 772 x 630 mm
Net Volume:
Non Insulated: 300 lt
Insulated: 285 lt
Weight (*): 90 KG
Max. Load Capacity of a Shelf: 40 KG
Height From Ground: 30 mm
*Depends on Configuration
External Dimensions (WxHxD):
606 x 1990 x 750 mm
Internal Dimensions (WxHxD):
Non Insulated: 603 x 1654 x 630 mm
Insulated: 584 x 1634 x 630 mm
Net Volume:
Non Insulated: 625 lt
Insulated: 600 lt
Weight (*): 134 KG
Max. Load Capacity of a Shelf: 40 KG
Height From Ground: 30 mm
*Depends on Configuration
External Dimensions (WxHxD):
606 x 1990 x 1050 mm
Internal Dimensions (WxHxD):
Non Insulated: 603 x 1654 x 930 mm
Insulated: 584 x 1634 x 930 mm
Net Volume:
Non Insulated: 925 lt
Insulated: 890 lt
Weight (*): 160 KG
Max. Load Capacity of a Shelf: 40 KG
Height From Ground: 30 mm
*Depends on Configuration
Comparison Table of XT Line Desiccant Dry Cabinets
✔ Standard • Optional • Not Available
CABINET MODEL | Stainless Steel Shelves | Dryer Unit | Second Dryer Unit | Smart N2 Flow Unit | Automatic Door Locks | RFID | Indoor Light | Heater Kit 45°C | Heater Kit 60°C | Heater Kit 100°C | Outside Temp. & HMD Sensor |
---|---|---|---|---|---|---|---|---|---|---|---|
XSC-300-01 Desiccant Dry Cabinet | |||||||||||
XSC-300-01 Desiccant Dry Cabinet | 2 | ✔ | • | • | • | • | • | • | • | • | • |
XSC-600-01 Desiccant Dry Cabinet | |||||||||||
XSC-600-01 Desiccant Dry Cabinet | 5 | ✔ | • | • | • | • | • | • | • | • | • |
XSC-900-01 Desiccant Dry Cabinet | |||||||||||
XSC-900-01 Desiccant Dry Cabinet | 5 | ✔ | • | • | • | • | • | • | • | • | • |
XTC-520-S8 Desiccant Dry Cabinet |
XS LINE SMART NITROGEN DRY CABINETS
X-Treme Series XS Line Smart Nitrogen Dry Cabinet has been specifically designed for drying and storing moisture sensitive devices (MSDs). According to IPC/JEDEC J-STD 033C ve IPC-1601 standards, moisture-sensitive materials and PCB’s can be stored in these cabinets for an unlimited period of time. XS Line Smart Nitrogen Dry Cabinets are suitable for low and medium volume production due to cabinet dimensions also it can be used for baking (floor life resetting) purposes with optional heater units up to 100ᵒC degree. Due to the long depth of the cabinet, feeder storage solutions can be added or used for the storage of large-scale products. XS Line Smart Nitrogen Dry Cabinets equipped with a smart nitrogen flow unit (N2AF-01). The N2AF-01 nitrogen flow unit guarantees constant low relative humidity ≤1%RH for short to long-term storage. A moisture-free and the oxygen-free environment is provided. Ideal for the moisture-proof and anti-oxidation storage of wide-ranging technologies.
X-Treme Series Smart Nitrogen Dry Cabinet keeps the moisture level at desired levels by optimally adjusting the nitrogen gas used thanks to its extensive software and sensitive sensors and saving money by minimizing the consumable usage level. According to process needs, nitrogen gas pressure can be increased, reduced, or nitrogen gas purging settings can be changed on the touch screen control panel to be specially shaped for the system. It provides you with a fully controlled, traceable, reliable environment.
The touch screen control panel provides 800x480px resolution in 7″ touch-capable area. The user can reach all important data in the cabinets with simple clicks. X-Treme Series Auto Dry Cabinets fully network compatible, it can be reached remotely via computers, phones, and tablets which are using Wi-Fi and ethernet connections. The cabinets are equipped with high-precision sensors and integrated data logger for performance traceability.
X-Treme Series Auto Dry Cabinets are ESD Safe and conforms to the current ESD 61340-5-1 standards with optional ESD-safe coating
External Dimensions (WxHxD):
606 x 1128 x 750 mm
Internal Dimensions (WxHxD):
Non Insulated: 603 x 792 x 630 mm
Insulated: 584 x 772 x 630 mm
Net Volume:
Non Insulated: 300 lt
Insulated: 285 lt
Weight (*): 90 KG
Max. Load Capacity of a Shelf: 40 KG
Height From Ground: 30 mm
*Depends on Configuration
External Dimensions (WxHxD):
606 x 1990 x 750 mm
Internal Dimensions (WxHxD):
Non Insulated: 603 x 1654 x 630 mm
Insulated: 584 x 1634 x 630 mm
Net Volume:
Non Insulated: 625 lt
Insulated: 600 lt
Weight (*): 134 KG
Max. Load Capacity of a Shelf: 40 KG
Height From Ground: 30 mm
*Depends on Configuration
External Dimensions (WxHxD):
606 x 1990 x 1050 mm
Internal Dimensions (WxHxD):
Non Insulated: 603 x 1654 x 930 mm
Insulated: 584 x 1634 x 930 mm
Net Volume:
Non Insulated: 925 lt
Insulated: 890 lt
Weight (*): 160 KG
Max. Load Capacity of a Shelf: 40 KG
Height From Ground: 30 mm
*Depends on Configuration
Comparison Table of XT Line Smart Nitrogen Dry Cabinets
✔ Standard • Optional • Not Available
CABINET MODEL | Stainless Steel Shelves | Dryer Unit | Second Dryer Unit | Smart N2 Flow Unit | Automatic Door Locks | RFID | Indoor Light | Heater Kit 45°C | Heater Kit 60°C | Heater Kit 100°C | Outside Temp. & HMD Sensor |
---|---|---|---|---|---|---|---|---|---|---|---|
XSC-300-N2 Smart Nitrogen Dry Cabinet | |||||||||||
XSC-300-N2 Smart Nitrogen Dry Cabinet | 2 | • | • | ✔ | • | • | • | • | • | • | • |
XSC-600-N2 Smart Nitrogen Dry Cabinet | |||||||||||
XSC-600-N2 Smart Nitrogen Dry Cabinet | 5 | • | • | ✔ | • | • | • | • | • | • | • |
XSC-900-N2 Smart Nitrogen Dry Cabinet | |||||||||||
XSC-900-N2 Smart Nitrogen Dry Cabinet | 5 | • | • | ✔ | • | • | • | • | • | • | • |
XTC-520-S8 Desiccant Dry Cabinet |
XS LINE HYBRID DRY CABINETS
XS Line Hybrid Dry Cabinets have been specifically designed for drying and storing moisture sensitive devices (MSDs). According to IPC/JEDEC J-STD 033C ve IPC-1601 standards, moisture-sensitive materials and PCB’s can be stored in these cabinets for an unlimited period of time. XS Line Hybrid Dry Cabinets are suitable for low and medium volume production due to cabinet dimensions also it can be used for baking (floor life resetting) purposes with optional heater units up to 100ᵒC degree. Due to the long depth of the cabinet, feeder storage solutions can be added or used for the storage of large-scale products. XS Line Hybrid Dry Cabinets are equipped both technologies desiccant drying unit (DHM-01) and smart nitrogen flow unit (N2AF-01). The N2AF-01 nitrogen flow unit guarantees constant low relative humidity ≤0.5%RH for short to long-term storage. A moisture-free and the oxygen-free environment is provided. Ideal for the moisture-proof and anti-oxidation storage of wide-ranging technologies.
While XS Line Hybrid Dry Cabinets prevent oxidation %100 with its smart nitrogen unit, it also makes the dehumidification process faster and more reliable with the desiccant dry units operating simultaneously. A smart nitrogen unit will continue drying process by taking control when the desiccant dry unit reaches saturation and regenerates itself automatically. In case the nitrogen source is interrupted or if there is a malfunction in any unit, the other unit takes over the control and provides a continuous drying process. For these reasons, they are the most efficient dry and storage solutions that can be used especially in long-term storage and drying processes.
XS Line Hybrid Dry Cabinets optimally adjust the nitrogen gas used thanks to its comprehensive software and sensitive sensors, keeping the humidity level at desired values and saving by minimizing the consumable usage level. Users can increase or decrease nitrogen gas pressure according to process needs or it can be tailored to the process by changing the nitrogen gas injection settings on the touch screen control panel. In this way, the user can decide which unit works how much.
The touch screen control panel provides 800x480px resolution in 7″ touch-capable area. The user can reach all important data in the cabinets with simple clicks. X-Treme Series Auto Dry Cabinets fully network compatible, it can be reached remotely via computers, phones, and tablets which are using Wi-Fi and ethernet connections. The cabinets are equipped with high-precision sensors and integrated data logger for performance traceability.
X-Treme Series Auto Dry Cabinets are ESD Safe and conforms to the current ESD 61340-5-1 standards with optional ESD-safe coating
External Dimensions (WxHxD):
606 x 1128 x 750 mm
Internal Dimensions (WxHxD):
Non Insulated: 603 x 792 x 630 mm
Insulated: 584 x 772 x 630 mm
Net Volume:
Non Insulated: 300 lt
Insulated: 285 lt
Weight (*): 90 KG
Max. Load Capacity of a Shelf: 40 KG
Height From Ground: 30 mm
*Depends on Configuration
External Dimensions (WxHxD):
606 x 1990 x 750 mm
Internal Dimensions (WxHxD):
Non Insulated: 603 x 1654 x 630 mm
Insulated: 584 x 1634 x 630 mm
Net Volume:
Non Insulated: 625 lt
Insulated: 600 lt
Weight (*): 134 KG
Max. Load Capacity of a Shelf: 40 KG
Height From Ground: 30 mm
*Depends on Configuration
External Dimensions (WxHxD):
606 x 1990 x 1050 mm
Internal Dimensions (WxHxD):
Non Insulated: 603 x 1654 x 930 mm
Insulated: 584 x 1634 x 930 mm
Net Volume:
Non Insulated: 925 lt
Insulated: 890 lt
Weight (*): 160 KG
Max. Load Capacity of a Shelf: 40 KG
Height From Ground: 30 mm
*Depends on Configuration
Comparison Table of XT Line Smart Nitrogen Dry Cabinets
✔ Standard • Optional • Not Available
CABINET MODEL | Stainless Steel Shelves | Dryer Unit | Second Dryer Unit | Smart N2 Flow Unit | Automatic Door Locks | RFID | Indoor Light | Heater Kit 45°C | Heater Kit 60°C | Heater Kit 100°C | Outside Temp. & HMD Sensor |
---|---|---|---|---|---|---|---|---|---|---|---|
XSC-300-DN2 Hybrid Dry Cabinet | |||||||||||
XSC-300-DN2 Hybrid Dry Cabinet | 2 | ✔ | • | ✔ | • | • | • | • | • | • | • |
XSC-600-DN2 Hybrid Dry Cabinet | |||||||||||
XSC-600-DN2 Hybrid Dry Cabinet | 5 | ✔ | • | ✔ | • | • | • | • | • | • | • |
XSC-900-DN2 Hybrid Dry Cabinet | |||||||||||
XSC-900-DN2 Hybrid Dry Cabinet | 5 | ✔ | • | ✔ | • | • | • | • | • | • | • |
XTC-520-S8 Desiccant Dry Cabinet |
Options & Accessories
Options are valid for all cabinet models
PCB Holder
PCB-01
Reel Holder
Stainless Steel (SS) SMD Reel Holder with 20 Divider Wire
Stainless Steel Shelf
Stainless Steel Shelf
Stainless Steel Sliding Shelf
Stainless Steel Sliding Shelf
45 °C Heater Kit
45°C Heater Kit for XS Line, XT Line and XL Line Cabinets
60 °C Heater Kit
60 °C Heater Kit for XS Line, XT Line and XL Line Cabinets
100 °C Heater Kit
100 °C Heater Kit for XS Line, XT Line and XL Line Cabinets
Automatic Door Locks
Automatic Door Locks by Password
Indoor Light
Indoor Light
Shelf Divider
Shelf Divider
Extraction Unit
Extraction Unit
U Divider
Stainless Steel (SS) U Divider for Cabinet Shelves
I Divider
Stainless Steel (SS) I Divider for Cabinet Shelves
Stabilization Legs
Adjustable Stabilization Legs 2 pcs
Outdoor Sensor
Outside Humidity and Temperature Sensor
External Alarm Bar
External Alarm Bar with Magnetic Base, 2-Color Light and Buzzer
N2 Flow Unit
N2 Auto Flow System
Humidifier Unit
HUM-01
Hepa Filter
Hepa Filter Option-Class 1000 (ISO 6)
UV Light
UV-A Type UV Light
Cooling Unit
COAF-01
MSD Track Software
MSD (Moisture Sensitive Device) Traceability Software
Version 3.0 Software
Embedded Software Upgrade to Version 3.0 from Version 2.0
