XL-LINE AUTO DRY CABINETS

XL Line Auto Dry Cabinets offer 1840LT volume within three different drying technologies

  • Dessiccant Dry Cabinets
  • Smart Nitrogen Dry Cabinets
  • Hybrid Dry Cabinets
XL Line-XLC-01-Desiccant Dry Cabinet

XL LINE DESICCANT DRY CABINETS

X-Treme Series Desiccant Dry Cabinets has been specifically designed for drying and storing moisture sensitive devices (MSDs). According to IPC/JEDEC J-STD 033C ve IPC-1601 standards, moisture-sensitive materials and PCB’s can be stored in these cabinets for an unlimited period of time. XL Line Desiccant Dry Cabinets are suitable for high-volume production due to cabinet dimensions also it can be used for baking (floor life resetting) purposes with optional heater units up to 100ᵒC degree. Due to the long depth of the cabinet, feeder storage solutions can be added or used for the storage of large-scale products. XL Line Desiccant Dry Cabinets are equipped with a patented drying unit DHM-01. The patented DHM-01 desiccant drying unit guarantees constant low relative humidity ≤0.5%RH for short to long-term storage thus oxidation risks associated with long term storage can be avoided. Ideal for the moisture-proof and anti-oxidation storage of wide-ranging technologies.

The drying unit of X-Treme Series Auto Dry Cabinets operating at very low humidity levels and optional heating units work together to provide a fast and healthy baking process at low temperatures for floor life resetting process. It provides a larger area and a more controlled drying environment compared to traditional ovens. Low-temperature baking prevents problems such as delamination, micro-cracks, popcorn affects, and solderability in MSDs (Moisture Sensitive Devices) arising due to high-temperature stress on the materials after baking in traditional ovens.

External Dimensions (WxHxD):
1200 x 1990 x 1050 mm
Internal Dimensions (WxHxD):
Non Insulated: 1197 x 1654 x 930 mm
Insulated: 1178 x 1634 x 930 mm
Net Volume:
Non Insulated: 1840 lt
Insulated: 1790 lt
Weight (*): 280 KG
Max. Load Capacity of a Shelf: 40 KG
Height From Ground: 30 mm

*Depends on Configuration

Comparison Table of XL Line Desiccant Dry Cabinets

Standard      • Optional      Not Available

X-TremeSeries-XTC-Serie-Desiccant-Dry-Cabinets-kiyaslama-tablosu
U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets
CABINET MODEL Stainless Steel Shelves Dryer Unit Second Dryer Unit Smart N2 Flow Unit Automatic Door Locks RFID Indoor Light Heater Kit 45°C Heater Kit 60°C Heater Kit 100°C Outside Temp. & HMD Sensor
XLC-01 Desiccant Dry Cabinet
XLC-01
Desiccant Dry Cabinet
  XLC-02 Desiccant Dry Cabinet
XLC-02
Desiccant Dry Cabinet
  XTC-520-S8 Desiccant Dry Cabinet
XL Line-XLC-01-Desiccant Dry Cabinet

XL LINE SMART NITROGEN DRY CABINETS

X-Treme Series Auto Dry Cabinets has been specifically designed for drying and storing moisture sensitive devices (MSDs). According to IPC/JEDEC J-STD 033C ve IPC-1601 standards, moisture-sensitive materials and PCB’s can be stored in these cabinets for an unlimited period of time. XL Line Smart Nitrogen Dry Cabinets are suitable for high-volume production due to cabinet dimensions also it can be used for baking (floor life resetting) purposes with optional heater units up to 100ᵒC degree. Due to the long depth of the cabinet, feeder storage solutions can be added or used for the storage of large-scale products. XL Line Smart Nitrogen Dry Cabinets are equipped with a smart nitrogen flow unit (N2AF-01). The N2AF-01 nitrogen flow unit guarantees constant low relative humidity ≤1%RH for short to long-term storage. A moisture-free and the oxygen-free environment is provided. Ideal for the moisture-proof and anti-oxidation storage of wide-ranging technologies.

X-Treme Series Smart Nitrogen Dry Cabinet keeps the moisture level at desired levels by optimally adjusting the nitrogen gas used thanks to its extensive software and sensitive sensors and saving money by minimizing the consumable usage level. According to process needs, nitrogen gas pressure can be increased, reduced, or nitrogen gas purging settings can be changed on the touch screen control panel to be specially shaped for the system. It provides you with a fully controlled, traceable, reliable environment.

External Dimensions (WxHxD):
1200 x 1990 x 1050 mm
Internal Dimensions (WxHxD):
Non Insulated: 1197 x 1654 x 930 mm
Insulated: 1178 x 1634 x 930 mm
Net Volume:
Non Insulated: 1840 lt
Insulated: 1790 lt
Weight (*): 280 KG
Max. Load Capacity of a Shelf: 40 KG
Height From Ground: 30 mm

*Depends on Configuration

Comparison Table of XL Line Smart Nitrogen Dry Cabinets

Standard      • Optional      Not Available

X-TremeSeries-XTC-Serie-Desiccant-Dry-Cabinets-kiyaslama-tablosu
U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets
CABINET MODEL Stainless Steel Shelves Dryer Unit Second Dryer Unit Smart N2 Flow Unit Automatic Door Locks RFID Indoor Light Heater Kit 45°C Heater Kit 60°C Heater Kit 100°C Outside Temp. & HMD Sensor
XLC-N2 Smart Nitrogen Dry Cabinet
XLC-N2
Smart Nitrogen Dry Cabinet
  XLC-02 Desiccant Dry Cabinet
XL Line-XLC-01-Desiccant Dry Cabinet

XL LINE HYBRID DRY CABINETS

X-Treme Series Auto Dry Cabinets has been specifically designed for drying and storing moisture sensitive devices (MSDs). According to IPC/JEDEC J-STD 033C ve IPC-1601 standards, moisture-sensitive materials and PCB’s can be stored in these cabinets for an unlimited period of time. XL Line Hybrid Dry Cabinets are suitable for high-volume production due to cabinet dimensions also it can be used for baking (floor life resetting) purposes with optional heater units up to 100ᵒC degree. Due to the long depth of the cabinet, feeder storage solutions can be added or used for the storage of large-scale products. XL Line Hybrid Dry Cabinets are equipped with both technologies desiccant drying unit (DHM-01) and smart nitrogen flow unit (N2AF-01). The N2AF-01 nitrogen flow unit guarantees constant low relative humidity ≤0.5%RH for short to long-term storage. A moisture-free and the oxygen-free environment is provided. Ideal for the moisture-proof and anti-oxidation storage of wide-ranging technologies. While X-Treme Series Hybrid Dry Cabinet prevents oxidation %100 with its smart nitrogen unit, it also makes the dehumidification process faster and more reliable with the desiccant dry units operating simultaneously. A smart nitrogen unit will continue drying process by taking control when the desiccant dry unit reaches saturation and regenerates itself automatically. In case the nitrogen source is interrupted or if there is a malfunction in any unit, the other unit takes over the control and provides a continuous drying process. For these reasons, they are the most efficient dry and storage solutions that can be used especially in long-term storage and drying processes.

External Dimensions (WxHxD):
1200 x 1990 x 1050 mm
Internal Dimensions (WxHxD):
Non Insulated: 1197 x 1654 x 930 mm
Insulated: 1178 x 1634 x 930 mm
Net Volume:
Non Insulated: 1840 lt
Insulated: 1790 lt
Weight (*): 280 KG
Max. Load Capacity of a Shelf: 40 KG
Height From Ground: 30 mm

*Depends on Configuration

Comparison Table of XL Line Hybrid Dry Cabinets

Standard      • Optional      Not Available

X-TremeSeries-XTC-Serie-Desiccant-Dry-Cabinets-kiyaslama-tablosu
U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets U-Divider-Shelve-Seperator-for-desiccant-dry-cabinets
CABINET MODEL Stainless Steel Shelves Dryer Unit Second Dryer Unit Smart N2 Flow Unit Automatic Door Locks RFID Indoor Light Heater Kit 45°C Heater Kit 60°C Heater Kit 100°C Outside Temp. & HMD Sensor
XLC-510-DN2 Desiccant Dry Cabinet
XLC-510-DN2
Desiccant Dry Cabinet
  XLC-520-DN2 Desiccant Dry Cabinet
XLC-520-DN2
Desiccant Dry Cabinet

Options & Accessories

Options are valid for all cabinet models
